2D Drawing to 3D Model
Blueprint
to 3D Reality.
Upload any engineering drawing and get a fully parametric, measurable 3D model in seconds — ready to section, inspect, and export for manufacturing.
The Process
From flat drawing
to solid geometry.
Upload Your Drawing
Drop in any 2D engineering drawing -scanned blueprint, CAD export, or photograph. The system reads dimensions directly from the image, no manual tracing required.
Automatic Dimension Reading
AI vision scans every annotation on the drawing and pulls out all critical dimensions -diameters, depths, bolt patterns, angles, tolerances, and surface finishes.
Review Before You Build
Every dimension is laid out for you to verify. Values that differ from standard ranges are flagged. You stay in control -edit anything before the model is generated.
Solid 3D Model Generated
The geometry engine constructs a true solid model from the parameters -flanges, bores, bolt holes, fillets, and chamfers are all built as real physical features, not textures.
Inspect, Measure, Export
Section through the model to verify internal geometry. Measure any distance in the viewer. Export as STEP for your CNC workflow, STL for printing, or OBJ for visualisation.
Solid Geometry
Real geometry.
Model Features -Built from Your Drawing
Capabilities
Built for
engineering accuracy.
Reads Any Engineering Drawing
Upload a scanned blueprint, a photograph of a hand drawing, or a digital PDF. The AI reads every annotated dimension -diameters, depths, bolt circles, port angles, tolerances, and surface notes.
Every Dimension is Editable
All extracted values are presented for your review before anything is built. Change a bore diameter, adjust a flange thickness, correct a bolt count -the model reflects exactly what you approve.
True Solid, Not a Shell
Internal bores, side passages, stepped cavities, and counterbores are cut through the full solid mass. Section the model at any point and the internal geometry is exactly what the drawing specifies.
Geometry Verified Before Delivery
Every model is checked for physical validity -wall thicknesses, bore clearances, bolt circle geometry, and angular consistency are all verified before the 3D model is shown to you.
Interactive Inspection Tools
Drag a section plane through the solid to reveal any internal feature. Click two points to measure a distance. Rotate and zoom freely. Every feature from the drawing is individually selectable.
Export for Any Downstream Use
Download as STEP to open in SolidWorks, Fusion 360, or FreeCAD for further machining work. Export as STL for 3D printing or FEA simulation. OBJ format for rendering and visualisation.
Get Started
Turn the next
drawing into
a 3D model.
Upload your drawing, confirm the dimensions the AI reads, and get a fully solid 3D model in seconds. Section it, measure it, then export directly into your manufacturing workflow -no manual CAD modelling required.
